Automatic Crushtester For ECT/RCT

Purpose:

This machine uses high precision sensor sensing to test paper like ring pressure strength, edge pressure strength and bonding，Strength and leveling strength and display the test values directly.



Features:

Three kinds of set speed,  LCD operation interface, a variety of units can choose the system to automatically calculate the ring pressure strength, edge pressure strength, no user manual calculation, reduce the workload and error

With the packaging heap code test function, can directly set the power, time, automatically stop after the test，After the completion of the test has the automatic return function, automatic judgment of the pressure failure force and automatically save the test data can record and save 20 test results.



Product Parameters:

Scope of measurement: ≤ 2 KN

Power unit: N, kN, kgf, gf, Ibf

Strength unit: Pa, kPa, MPa, kgf/cm2, Ibf/in2

Test speed: 12.5 mm/min

Value accuracy: soil 1%

Resolution: 1N

Pressure disc size: φ110 mm

Distance between upper and lower pressure discs: 60 mm

Power supply: 220V/ 1.5A
